Question:
My results for the calculation with warping torsion are implausible. What could be the reason?
Answer:
First of all, it would be advantageous to examine the boundary conditions for the design again. This includes, among other things, the selected load approach, checking the transverse stiffeners and the transitions between the members. It is also useful to check the calculation theory outside of the second-order theory due to large rotations.
However, it is also particularly important that in RFEM, a division of the FE mesh is required for warping torsion.
You can do this by checking the FE mesh settings and the graphical representation of the member FE mesh.
For more information, go to the FAQ page:
► https://www.dlubal.com/en-us/support-and-learning/support/faq/005281
